P5000 Platform Lift
The P5000 Platform Lift is a compact, cost-effective vertical transport solution engineered to meet the demands of both residential and commercial environments. Designed with simplicity and adaptability in mind, it offers full functionality without the need for a pit, lifting beam, machine room or separate shaft—making it particularly well-suited to existing buildings, listed properties, and restricted spaces.
With its self-contained design, the P5000 is quick to install, low in maintenance, and rated “A” for energy efficiency. It operates using a self-lubricating screw and nut drive system with a concealed motor, ensuring smooth, quiet operation without compromising reliability.
Smart, Space-Efficient Vertical Access
This P5000 is available in a wide range of platform sizes, finishes, and configurations, including fire-rated and fully glazed aluminium doors, making it one of the most flexible and design-conscious lifts in its class. Choose from a wide palette of RAL colours, flooring options, and stainless-steel detailing to match your architectural or interior scheme.
Ideal for schools, offices, healthcare settings, apartments, retail spaces, and private homes, the P5000 is fully certified under the European Machinery Directive 2006/42/EC and offers:
- Rated loads of 300–500 kg and travel heights up to 13 metres
- Up to 6 stops and multiple door configurations
- Standard 2-stop installation in as little as 2 days
- 2-year warranty on motor and drive nut
- Optional outdoor version with reinforced, weatherproofed construction for exposed installations
From simple access improvements to complex retrofits, the P5000 offers a high-performance solution with minimal disruption and maximum design flexibility—making it a trusted choice for a broad range of lifting requirements.
Why Choose the P5000?
The P5000 platform lift is available in a range of configurations to suit different building types, design preferences, and performance requirements. Whether you’re installing in a residential property, a public building, or a commercial space, the P5000 offers the versatility to meet a wide variety of needs.
Lift Sizes & Capacities
- Available in multiple platform sizes, accommodating spaces from compact private settings to more spacious public access requirements.
- Load capacities range from 300kg to 500kg, with platform widths from 900mm to 1100mm, depending on layout and specification.
Door Options
- Manual or automatic doors, available to suit both aesthetic and functional needs.
- Choose from half-height or full-height doors, with options for aluminium framed, fully glazed, or fire-rated models for compliance with building regulations.
Entry Configurations
Multiple entry configurations including:
- Same side (Type 1)
- Through-car (Type 2)
- Adjacent entry (Type 3)
These options allow for flexibility depending on building layout, corridor access, and architectural requirements.
Indoor and Outdoor Use
- Standard design suited for indoor installations in homes, schools, offices, and retail environments.
- Outdoor version available, reinforced with weather-resistant materials and structural protection to ensure long-term performance in exposed environments.
Control & Power Supply Options
- Available with hold-to-run controls (standard) or automatic operation at landings (optional).
- Operates on single-phase (230V) or three-phase (400V) power, depending on site requirements.
Features
Compact, Self-Contained Design
No need for separate machine room, pit, or lifting beam
Quiet Operation
Designed for smooth and silent vertical travel
Quick Installation
Minimal building works; ideal for retrofit projects
Flexible Configuration
Available in a variety of platform sizes and door arrangements
Custom Finishes
Wide choice of RAL colours, flooring materials, and stainless-steel trim options
Accessibility Compliance
Designed to support DDA, Equality Act and Part M requirements
Glazed and Fire-Rated Door Options
Including fully glazed aluminium framed doors
Safety Features
Emergency lowering, safety edge, hold-to-run controls, and automatic re-levelling
Outdoor Durability
Optional reinforced, weather-resistant version for external applications
Low Maintenance
Long-lasting components with minimal servicing needs
Specification
| DRIVE SYSTEM | Self-lubricating screw and nut with concealed motor |
| RATED LOAD | 300kg to 500kg (model dependent) |
| MAX TRAVEL | Up to 13 metres |
| SPEED | Approx. 0.15 m/s |
| STOPS | Up to 6 |
| CONTROLS | Hold-to-run operation (standard), automatic operation (optional on landings) |
| POWER SUPPLY | 1-phase 230V or 3-phase 400V |
| ENERGY | Rated “A” (low consumption) |
| CERTIFICATE | Machinery Directive 2006/42/EC |
| SIZES | Multiple standard and bespoke options |
| INSTALLATION | Typical 2-stop installation completed in as little as 2 days |
| SHAFT | Supplied with own structure-supported shaft |
| PIT | No pit required (standard ramp or shallow pit optional) |
| WARRANTY | 2-year warranty on motor and drive nut |
| USAGE | Indoor or outdoor (optional weatherproof outdoor version available) |
